MYPIN Only LKV373 HDMI 1080P Receiver For Extender Up to 100-120 Meters Over CAT5E CAT6

Product description

Description:

This LKV373 HDMI receiver is designed to convert HDMI signal to standard TCP/IP and transmit by CAT5e/6 Cable or LAN. With the advantage of TCP/IP standard, it can transmit HDMI signal source from HD STB, DVD, PS3, HDMI display card etc to HD projector, DLP, LCD, LED and other audio visual equipments. It needs to match our LKV373 sender to use.

Features:

1. Apply M-JPEG technology to process image compressing.
2. Supported HDMI format: 480i@60Hz, 480p@60Hz, 576i@50Hz, 576p@50Hz, 720p@50/60Hz, 1080i@50/60Hz, 1080p@50/60Hz
3. Supports TCP/IP, extends HDMI signal unlimitedly over router or hub/switch
4. Follow the standard of IEEE-568B
5. Supports resolutions up to 1080p Full HD
6. It can transmit HDMI 1080P signal to above 120M by using UTP CAT6.
7. Supports Ethernet bandwidth: 100M
8. HDCP compliant

Specification:

• Supports resolutions: 480i@60Hz, 480p@60Hz, 576i@50Hz, 576p@50Hz, 720p@50/60Hz, 1080i@50/60Hz, 1080p@50/60Hz
• Working Temperature: -10℃ ~ 60 ℃
• Link Connector（Receiver): UTP/STP CAT5e/6
• Power Consumption: 3W (max) each
• Relative Humidity: 20% ~ 90%
• Power Supply: DC 5V/1A
• Dimensions: 110 x 58 x 26 mm
• Cat5e/6 cable: Follow the standard of IEEE-568B

Package Included:

• 1 x HDMI Extender Receiver
• 1 x DC 5V/1A power Supply
• 1 x User manual

Please note: This listing only include a Receiver (not include sender). This item is only new 2.0-Version, before you buy it, please check the version for your sender(transmitter), if your sender is old version, please don’t buy it.
